The MRCOOL® Advantage 5th Generation 18,000 BTU Mini-Split Heat Pump offers reliable, high-efficiency heating and cooling for rooms up to 800 sq. ft. Designed for year-round comfort, this ductless system features a WiFi-compatible indoor air handler and a corrosion-resistant outdoor condenser with Gold Fin® protection. It uses next-generation R-454B refrigerant, which provides significant environmental benefits with 80% lower Global Warming Potential than traditional R-410A.

With a SEER2 rating of 19.2 and HSPF2-4 rating of 9.6, this unit balances performance and energy savings. Remote access is available through the MRCOOL® SmartHVAC app and via voice control with Google Assistant and Amazon Alexa. The included remote features Follow Me® technology, sensing your location for a personalized comfort experience.

Additional features include quiet operation, built-in leak detection, timer mode, and advanced diagnostics. A professional HVAC technician must install the system to maintain warranty coverage and ensure proper performance.

Key Features

• Smart Control Integration – Built-in WiFi supports Amazon Alexa, Google Assistant, and the MRCOOL® SmartHVAC app.


• High Efficiency – Rated at 19.2 SEER2 and 9.6 HSPF2-4 for strong year-round energy savings.


• Follow Me® Function – Remote control detects your location to deliver custom comfort where you are.


• Quiet Operation – Indoor operation as low as 19 dB(A), ideal for bedrooms and offices.


• Eco-Friendly Refrigerant – R-454B refrigerant has 80% lower GWP compared to R-410A.


• Gold Fin® Condenser Protection – Resists corrosion in humid or coastal environments.


• Low Ambient Operation – Operates in temperatures as low as 5°F for both heating and cooling.


• Built-In Diagnostics – Includes timer mode and refrigerant leak detection for efficient, safe performance.

  Professional Installation Required – Must be installed by a licensed HVAC professional.


• Warranty Coverage – 1-year parts and remote, 2-year compressor; optional lifetime compressor coverage with MRCOOL® Care.

Specifications

• Brand: MRCOOL®


• Series: Advantage 5th Generation


• Product Type: Single-Zone Ductless Mini-Split Heat Pump


• Voltage: 230V, 1 Phase, 60 Hz


• Cooling Capacity: 18,000 BTU


• Heating Capacity: 18,800 BTU


• SEER2 Rating: 19.2


• EER2 Rating: 10.8


• HSPF2-4 Rating: 9.6


• HSPF2-5 Rating: 7.5


• Coverage Area: Up to 800 sq. ft.


• Zone Capacity: 1


• Outdoor Operating Temperature (Cooling): 5°F – 122°F


• Outdoor Operating Temperature (Heating): 5°F – 86°F


• Refrigerant Type: R-454B


• Refrigerant Volume: 40.57 oz


• Liquid Line Size: 1/4"


• Suction Line Size: 1/4"


• Max Line Set Length: 98.4 ft.


• Indoor Noise Level (Hi/Mi/Lo): 50.5 / 45 / 36 / 24 / 19 dB(A)


• Outdoor Noise Level: 56.0 dB(A)


• Compressor Type: Rotary


• Inverter: DC


• Condenser Dimensions: 31.69" W x 12.99" D x 21.81" H


• Air Handler Dimensions: 37.99" W x 8.46" D x 12.56" H


• Condenser Weight: 72.31 lbs


• Air Handler Weight: 24.47 lbs


• Max Fuse Breaker: 20A


• Min Circuit Ampacity: 15A


• Wifi Compatibility: Yes


• App Compatibility: Yes


• Works with iOS: Yes


• Works with Android: Yes


• Remote Control Included: Yes


• Fan Only Option: Yes


• Quiet Mode: Yes


• Auto Cool: Yes


• Certifications: UL Listed, CSA Listed, ETL Listed, AHRI Certified


• Warranty: 1-Year Parts, 2-Year Compressor, 1-Year Remote; Optional Lifetime Compressor Coverage with MRCOOL® Care Program

BTU Size Chart

Which BTU rating should I choose?

• The appropriate BTU rating depends on the size of the space you need to heat or cool.
• A higher BTU indicates greater heating and cooling capacity, allowing the air handler to effectively condition larger areas.

*Ceiling height, insulation quality, and local climate can all affect the actual coverage area. For instance, an uninsulated space will need more BTUs to maintain comfort compared to a well-insulated room.
